We are distinguished exporter and manufacturer of Liquid Sachet Filling Machine. Owing to our state-of-the-art infrastructure and technology we have been able to deliver our customers exactly what they need. sturdy construction, corrosion & Abrasion resistance and cost effectiveness are some of its remarkable features of the machine. High-grade components are procured from some of the certified vendors in the industry to fabricate this Liquid Sachet Filling Machine.
Model AP - 600L-Up to 7 Tracks is capable of running up to a speed of 75 SPM and has the capacity of 7 tracks. This machine can easily pack 200 ML of item and is installed with varied film draw mechanisms like as servo based and electromagnetic break & clutch. Our machine is acknowledged for high durability and efficiency. Besides we strive to make delivery of filling machine within stipulated time.
| Machine speed | Up to 90 SPM/Per Track depending on the product & sachet/pouch dimension. |
| Packing range | Suitable to pack up to 200 ml and depending upon product to be packed |
| No. of tracks | Up to 7 tracks depending on sachet/pouch width |
| Max. roll width | 600 mm |
| Max. roll dia | 350 mm |
| Max length of pouch | Up to 200 mm |
| Film draw mechanism | Options Servo based Electromagnetic clutch and break |
| Web controller | Options Electronic web edge control. Pneumo hydraulic web edge controller |
| Compressed air | 2CFM @ 6 kg/cm sq. |
| Electrical power required | Up to 6KW |
| Main Body Frame | Option MS with Powder coating. MS with SS cladding |
| Type of Sealing | 4 Side Sealing |
| Machine dimension | 2830 mm X 1300 mm X 2000 (Height mm X Width mm X Length mm) |
| Net weight | 1800 kg |
